The thread forming tap according to claim 4, wherein in the one lead, the male thread portion is provided with the same number of and a plurality of the at least one protruding portion and the at least one adjustment portion, and the at least one protruding portion and the at least one adjustment portion are alternately arranged in the one lead.ġ1. The thread forming tap according to claim 3, wherein in the one lead, the male thread portion is provided with the same number of and a plurality of the at least one protruding portion and the at least one adjustment portion, and the at least one protruding portion and the at least one adjustment portion are alternately arranged in the one lead.ġ0. The thread forming tap according to claim 2, wherein in the one lead, the male thread portion is provided with the same number of and a plurality of the at least one protruding portion and the at least one adjustment portion, and the at least one protruding portion and the at least one adjustment portion are alternately arranged in the one lead.ĩ. The thread forming tap according to claim 1, wherein in the one lead, the male thread portion is provided with the same number of and a plurality of the at least one protruding portion and the at least one adjustment portion, and the at least one protruding portion and the at least one adjustment portion are alternately arranged in the one lead.Ĩ. The thread forming tap according to claim 3, wherein the ridge diameter of the first thread ridge in the one lead is longer than a ridge diameter of the second thread ridge.ħ. The thread forming tap according to claim 2, wherein the ridge diameter of the first thread ridge in the one lead is longer than a ridge diameter of the second thread ridge.Ħ. The thread forming tap according to claim 2, wherein a contour of a cross section of the second root in the axial direction that passes through the axial center is a straight line shape.Ĥ. The thread forming tap according to claim 1, wherein the at least one adjustment portion includes a plurality of second thread ridges arranged in the axial direction and protruding in the radial direction, and a second root formed between the second thread ridges adjacent to each other in the axial direction, and a root diameter of the second root is longer than the root diameter of the first root, and shorter than the ridge diameter of the first thread ridge adjacent to the first root.ģ. A thread forming tap for forming a female thread by causing plastic deformation of a prepared hole of a workpiece, the thread forming tap comprising: a male thread portion protruding in a thread shape in a radial direction, the male thread portion including: at least one protruding portion including a plurality of first thread ridges arranged in an axial direction and protruding in the radial direction, and a first root formed between the first thread ridges adjacent to each other in the axial direction and at least one adjustment portion arranged with the at least one protruding portion in one lead of the male thread portion, a distance from an axial center to a section of the adjustment portion corresponding to the first root in the one lead being longer than a root diameter of the first root and shorter than a ridge diameter of the first thread ridge adjacent to the first root.Ģ. A distance from an axial center to a section of the adjustment portion corresponding to the first root in the one lead is longer than a root diameter of the first root and shorter than a ridge diameter of the first thread ridge adjacent to the first root.ġ. The male thread portion includes at least one protruding portion ( 5), which includes a plurality of first thread ridges ( 51) arranged in an axial direction and that protrude in the radial direction and a first root ( 52) formed between the first thread ridges adjacent to each other in the axial direction, and at least one adjustment portion ( 6), which is arranged with the at least one protruding portion in one lead of the male thread portion. A thread forming tap ( 1) is a cold forming tap for forming a female thread by causing plastic deformation of a prepared hole of a workpiece, and includes a male thread portion ( 3) that protrudes in a thread shape in a radial direction. An object is to provide a thread forming tap configured to obtain an inside diameter dimension of a female thread having a targeted processing accuracy more easily than in related art.
